Mode
| Scan Cobot P
|
Scanning mode
| Non-contact three-dimensional scanning ( photographic three-dimensional scanning )
|
Projection, grating technology
| Microstructure light projection and extrapolation multi-frequency phase shift technology
|
Calibration Technique
| Loop coding calibration ( 13 steps )
|
Single scan range ( mm )
| Independent mode | 400×300
|
100×75
|
Regulatory mode
| 200×150
|
50×40
|
Single measurement accuracy ( mm )
| ±0.01
|
Single-sided scanning time ( s )
| ＜5，＜3
|
Splicing method
| Automatic intelligent splicing, manual feature splicing
|
Scannable object range ( mm )
| 30～1500
|
Average sampling point distance ( mm )
| 0.06-0.47
|
Industrial three-dimensional photogrammetry ( Accuracy )
| Support industrial three-dimensional photogrammetry splicing project coordinate point file import
|
Industrycamera
| Resolution ( pixels )
| 1.31 million pixels
|
Camera angle ( degree )
| 18 degrees, 27 degrees, 32.5 degrees
|
Industrial lens ( mm )
| 8, 12, 16, 25, 35 depending on the model configuration
|
Calibration unit
| Metal / Glass / Granite
|
Industrial operation table
| Mobile tripod / professional workbench / heavy operating frame
|
Data output format
| ASC，STL，PLY, IGES
|
Operating system
| Windows xp / windows7 / windows10 32-bit / 64-bit Chinese / English
|
Light source, energy ( W )
| Standard 100 W halogen LED, 50 W high-energy LED ( White ) ; high-energy lamp ( HPL ) 250 W halogen lamp
|
Calibration board
| Square granite material calibration plate
|
Working temperature, power supply
| 0～40℃、100～240V AC
|
Examining report
| The equipment accuracy test report and calibration version accuracy test report issued by the metrology quality inspection institute
|
Camera platform
| 360 degree free adjustment platform before and after
|
Scanister
| System Size ( mm )
| 440x140x120
|
System weight ( kg )
| 2.5
|
