Product model

Galaxy 57

Light source

57 blue laser lines (wavelength: 450nm)

Measuring speed

3,350,000points/s

Scan mode

Standard mode

Deep hole mode

Precision mode

34 crossed blue laser lines

1 blue laser line

22 crossed blue laser lines

Data accuracy

0.02mm

0.02mm

0.01mm

Scanning distance

450mm

450mm

450mm

Scan depth of field

550mm

550mm

200mm

Resolving power

0.01mm(max)

Scanning area

800×600mm

Scanning range

0.1-10M（expandable）

Volumetric accuracy

0.02+0.035mm/m

0.02+0.015mm/m  combined with hl-3dp 3D global Photogrammetry System (optional)

Operating software

HLScan（lifetime free upgrade）

Support data format

asc、stl、ply、obj、igs 、wrl、xyz、txt Etc., customizable

Compatible software

3D Systems（Geomagic Solutions）、InnovMetric Software（PolyWorks）、Dassault Systemes（CATIA V5和SolidWorks）、PTC（Pro/ENGINEER）、Siemens（NX和Solid Edge）、Autodesk（Inventor、Alias、3ds Max、Maya、Softimage）Etc.

Data transmission

USB 3.0

Computer configuration (optional)

Win10 64 bit; Video memory: 4G; Processor: i7-8700 and above; Memory: 64 GB

Laser safety class

ClassⅡ(eye safety）

Certification number（Laser certificate）：LCS200726001DS

Equipment weight

920g

Overall dimension

290x125x70mm

Temperature / humidity

-10—40℃；10-90%

Power Supply

Input:100-240v,50/60Hz,0.9-0.45A；Output:24V,1.5A,36W(max)

Authentication

CE、IC、FCC、ROHS、ISO9001

Patent

ZL201220386542.3，ZL201220386546.1，ZL201520174157.6，ZL201721695684.7，ZL201520174106.3，ZL201420058854.0，ZL201721376035.0，ZL201330658475.6，ZL201130007136.2，ZL201130007145.1，ZL201130007141.3，ZL201720362488.1，ZL201720349729.9，ZL201720362493.2，ZL201720369852.7，ZL201720369914.4，ZL201720369921.4，ZL2021102492208.4

Warranty period

24 natural months
